Structural Detailing of a Tank Tower

By El-Bethel Buyanzi

This structural detailing of a tank tower was done using AutoCAD after design and analysis using a combination of manual calculations and Prokon. The detailing shows the curtailment of beams to reduce the cost of reinforcement required during construction. Material specifications: Fyk = 500, Fck= C25
